    Ruby Plus

    Ruby Plus series (RP128) is a new 128-beam mechanical LiDAR specifically designed for L4+ autonomous driving. Compared with RS-Ruby Series, it has reduced volume by 50%, weight by 52% and power consumption by 33% for a greatly improved performance.

    ₹15,56,080Excl. GST
    Technical Details

    Specifications

    Technical Specifications

    Product Features

    Technical features and specifications for Ruby Plus
    FeatureValue
    Number of Channels128 Channels
    FOV360°×40°
    Horizontal Resolution
    • 1. 0.2°
    • 2. 0.4°(Balanced Mode) 0.1°
    • 3. 0.2(High-PerformanceMode)
    Vertical Resolution0.1°(104 Channels)
    Ultra-high resolution0.1°×0.1° at 10 Hz
    Number of Output Points
    • 1. ~2,304,000 pts/s (single Return Mode)
    • 2. ~4,608,000 pts/s (dual Return Mode)
    Range250m(240m@10% NIST)
    Dimensions125 mm × H128 mm
    Power Consumption27 W - 32 W
    Temperature-40°C ~ +60°C (operating), -40°C ~ +85°C (storage)
    Ingress ProtectionIP67, IP6K9K
    Weight(without cable)1920g±50g
