Edge Computers · HyperEdge Series
HyperEdge U300
HyperEdge U300 is a compact AI edge computer powered by NVIDIA Jetson Orin Nano and Orin NX modules, delivering up to 157 TOPS of AI performance for intelligent edge applications. Designed for robotics, UAVs, video analytics, intelligent inspection, smart buildings, and remote monitoring systems, it enables real-time AI inference and autonomous decision-making. Built for field-deployed and distributed AI environments, it offers the flexibility required for remote intelligent systems operating beyond traditional industrial settings
Built For Demanding
Applications
The HyperEdge U300 is engineered for compact AI inference, deployment flexibility, and intelligent edge applications.
VIDEO ANALYTICS
AUTONOMOUS ROBOTS
UAV & DRONES
INDUSTRIAL INSPECTION
SMART BUILDINGS
LOW-ALTITUDE DEFENSE
Specifications
Technical Specifications
Computer Module — Nvidia Jetson Orin Nx
| Parameter | Orin Nx 8gb Variant | Orin Nx 16gb Variant |
|---|---|---|
| AI Performance | 70 TOPS (Super Mode:117 TOPS) | 100 TOPS (Super Mode:157 TOPS) |
| GPU | 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores | |
| CPU | 6 core Arm® Cortex® A78AE v8.2 64bit (1.5MB L2 + 4MB L3) | 8 core Arm® Cortex® A78AE v8.2 64bit (2MB L2 + 4MB L3 |
| Memory | 8GB 128-bit LPDDR5 102.4 GB/s | 16GB 128-bit LPDDR5 102.4 GB/s |
| Video Encode | 1x 4K60 | 3x 4K30 | 6x 1080p60 | 12x 1080p30 | |
| Video Decode | 1x 8K30 | 2x 4K60 | 4x 4K30 | 9x 1080p60 | 18x 1080p30 | |
| eMMC | Supports external NVMe | |
Computer Module — Nvidia Jetson Orin Nano
| Parameter | ORIN Nano 4GB VARIANT | ORIN Nano 8GB VARIANT |
|---|---|---|
| AI Performance | 20 TOPS (Super Mode:34 TOPS) | 40 TOPS (Super Mode:67 TOPS) |
| GPU | 512-core NVIDIA Ampere architecture GPU with 16 Tensor Cores | 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores |
| CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit (1.5MB L2 + 4MB L3) | |
| Memory | 4GB 64bit LPDDR5 34GB/s | 8GB 128bit LPDDR5 68GB/s |
| Video Encode | 1080p30 supported via CPU cores | |
| Video Decode | 1× 4K60 | 2× 4K30 | 5× 1080p60 | 11× 1080p30 | |
| eMMC | Supports external NVMe | |
I/O Interfaces
| Interface | Specification |
|---|---|
| Ethernet | 1 x RJ45 Gigabit Ethernet port |
| USB | 2x USB 3.0 Type-A |
| Serial Ports | 1x RS-232, 1× CAN |
| USB OTG | 1x Micro USB OTG |
| Video Output | 1× HDMI |
| RTC | 1× Real-Time Clock |
Expansion & Storage
| Slot | Specification |
|---|---|
| Mini PCIe | 1x Mini PCI Express socket for 4G cellular module, with internal SIM socket |
| M.2 Key E | 1× M.2 2230 Key E socket for Wi-Fi /Bluetooth module |
| M.2 Key M | 1× M.2 2242 Key M socket for NVMe SSD |
Power & Control
| Parameter | Specification |
|---|---|
| Power Input | DC Barrel Connector, 12–24 VDC |
| Buttons | 3× buttons — Power(PWR), Recovery (REC) and Reset (RST) |
| Indicators | 1× LED indicators — Power status |
Mechanical
| Parameter | Specification |
|---|---|
| Dimensions | 109.2mm×62.5 mm×46.3 mm |
| Mounting | Wall Mount |
| Enclosure | Rugged Aluminum Alloy |
Environmental
| Parameter | Specification |
|---|---|
| Operating Temperature | -20°C to +60°C - Super Mode: -20°C to +40°C (Orin NX) -20°C to +60°C (Orin Nano) |
| Cooling | Active Fan Cooling |
| Humidity | 5%–95% Non-Condensing |
Package Contents & Accessories
| Packing List | |
|---|---|
| Main Unit | HyperEdgee U300 |
| Mounting | Wall Mount assembly with screws |
| JST Cable Connector | 4-Pin A1245 GH Type 1.25mm Connector with 10cm Wire |
| Standard Accessories | |
| Power Adapter | MeanWell GST 90W AC-DC Power Adaptor (12VDC/7.5A) |
| Power Cable | EU1-MC13 1.8M Universal Power Cable |
| Optional Accessories | |
| Wi‑Fi Module | Wireless AW-CB375NF NIC, Dual-band Wi-Fi 5, BT 5.0 |
| 4G LTE Module | Quectel EG25-G 4G LTE Cat 4 global-band Mini PCIe Module |
| Wi‑Fi Antenna | 2.4GHz - 5 GHz, 5 dBi Omni Wi-Fi Antenna with SMA connector |
| 4G Antenna | 600–6000 MHz, 5 dBi Omni 4G Antenna with SMA connector |
| Storage | Customizable with 128GB, 256GB, 512GB, 1TB, 2TB, and 4TB capacities |
Ordering Information
| System Core | Model Number | Action |
|---|---|---|
| NVIDIA Jetson Orin Nano 4GB | HEU300ONO4G | |
| NVIDIA Jetson Orin Nano 8GB | HEU300ONO8G | |
| NVIDIA Jetson Orin NX 8GB | HEU300ONX8G | |
| NVIDIA Jetson Orin NX 16GB | HEU300ONX16G |
Overview
HyperEdge U300 Industrial AI Edge Computer for Machine Vision & Robotics
The HyperEdge U300 is a high-performance AI Edge Computer designed for industrial automation, machine vision, robotics, and intelligent edge computing applications. Powered by Jetson Orin NX, and Jetson Orin Nano, it delivers powerful AI inference, accelerated computing, and real-time data processing for demanding edge AI workloads. Built for applications requiring computer vision, object detection, deep learning, video analytics, and intelligent automation, the HyperEdge U300 provides reliable performance and scalable AI computing capabilities. Its advanced edge processing architecture enables low-latency decision-making and efficient deployment in industrial environments. The HyperEdge U300 AI Edge Computer is well suited for robotic systems, Autonomous Mobile Robots (AMRs), Automated Guided Vehicles (AGVs), smart manufacturing, industrial inspection, intelligent surveillance, and autonomous machine applications. Its powerful AI capabilities support real-time monitoring, predictive analytics, and intelligent process automation. With industrial-grade reliability, flexible NVIDIA Jetson integration, and advanced AI processing performance, the HyperEdge U300 helps organizations accelerate digital transformation and deploy next-generation intelligent edge computing solutions across a wide range of industries.
